  • Is it okay to install my microwave over a gas range?

    Yes. All of our over-the-range (OTR) microwaves are certified by Underwriters Laboratories for use over a gas range.

  • Why do metal objects spark or arch when I use them in the microwave, but the metal rack that comes with the microwave doesn’t?

    Unlike other metal objects, the metal rack included with your microwave is specially designed for safe use. The design takes into account the pattern of microwaves to prevent arching and sparks. For example:
    • The plastic spacers which hold the rack in place are engineered to keep it from arching against the microwave’s sides.
    • The rack’s tines and outer edges are engineered to form a fully enclosed object, avoiding the open ends that lead to arching.
    No other metal objects, including pans, utensils, etc. are approved for use inside a microwave.

  • Where does my OTR microwave vent?

    All of our over-the-range (OTR) microwaves are factory preset to vent internally – it will recirculate the air back into the room. However, it can also be converted to vent externally, or outside, if you prefer. If this is your preference, please let the installer know before they begin the initial installation and they will share the option that best suits your installation situation.

  • What hardware should I use for installing my microwave?

    Your over-the-range (OTR) microwave, it will come with all the necessary installation hardware. Each of our models comes with a complete set of installation hardware.

  • Do I need a special plate to cook popcorn in my microwave?

    If your microwave model has a glass tray or turn table, then follow the instructions printed on the popcorn label and place the bag on the turn table. In some instances, if you have a metal turn table (instead of glass), you do need to set the popcorn bag on a popcorn/bacon plate. This plate will lift the popcorn bag off of the microwave’s metal turntable, which can otherwise interfere with the metal contained in the popcorn bag.


General Specifications

  • Product Weight (lbs): 36
  • Frigidaire Collection: Yes
  • Shipping Weight (lbs): 44
  • ProductLaunch: NA
  • Power Type: Electric
  • Size: 1.6 Cu. Ft.
  • Installation Type: Built-In
  • Collection: Frigidaire


  • Start Button: Yes
  • Touch Pad Buttons: 23
  • Power Levels: 10
  • Add 30 Seconds: Yes
  • Numeric Touch Pad: Yes
  • Display Color: White
  • Display Type: LED
  • Quick Settings (Time): Yes 1 - 3
  • Timer Function: 99:99
  • Electronic Clock: Yes - Separate Button
  • Stop / Cancel Button: Yes
  • Controls: Membrane

Auto Features

  • Auto Defrost Options: Yes
  • Auto Cook Options: 1
  • Keep Warm: Yes

Certifications & Approvals

  • UL/cUL Approval: Yes

Exterior Dimensions

  • Depth: 18-1/2"
  • Width: 21-3/4"
  • Height: 12-7/8"

Microwave Oven Specifications

  • Watts: 1100
  • Frequency (Mhz): 2450
  • Interior Light Wattage: 30
  • Microwave Turntable Diameter: 14-1/4"

Sensor Features

  • Vegetable Cook Sensor: Yes
  • Reheat Button: Yes
  • Popcorn Button: Options for 1.75/3.0/3.5 oz.
  • Baked Potato Button: Yes
  • Sensor Cook Options: Yes
  • Cooking - Multiple Stages: Yes - 2 Stages


  • 30" Built-in Trim Kit (White): Optional order item no. FFMOTK30LW
  • 27" Built-in Trim Kit (Black): Optional order item no. FFMOTK27LB
  • 27" Built-in Trim Kit (White): Optional order item no. FFMOTK27LW
  • 30" Built-in Trim Kit (Black): Optional order item no. FFMOTK30LB

User Modes

  • Clock: Yes - Separate Button
  • Child Lock: Yes

Electrical Specifications

  • Amps @ 120 Volts: 13
  • Voltage Rating: 120V 60Hz
  • Power Supply Connection Location: Rear
  • Connected Load (kW Rating) @ 120V: 1.55

Internal Dimensions

  • Microwave Interior Depth: 15-3/8"
  • Microwave Interior Width: 17-1/4"
  • Microwave Interior Heigh: 10-5/16"


  • Capacity (Cu. Ft.): 1.6
